3.1 kHz Bandwidth |
|
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Higher responsiveness and shorter settling time increases productivity |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
![](http://www.deltaww.com/filecenter/Products/Images/06/060201/ASDA-A3_feature1_EN.jpg) | |
|
|
|
24-bit Absolute Type Encoder |
|
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
16,777,216 pulses/turns ensure precise positioning |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Steady performance at low-speed enhances machining quality |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Keeps motor's position during power shortage |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
![](http://www.deltaww.com/filecenter/Products/Images/06/060201/ASDA-A3_feature2_EN.jpg) | |
|
|
|
Advanced Motion Control E-CAM & 99 sophisticated motion |
|
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
E-CAM & 99 sophisticated motion commands and segments allowed |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Graphical user interface offers simple setup and programming |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Arithmetic operation / comparison commands available |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
General motion functions such as homing, position and speed commands |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Superimposition, blending, and jump change motion commands provided |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
![](http://www.deltaww.com/filecenter/Products/Images/06/060201/PR-Chart.jpg) | |
|
|
|
Comprehensive Auto-Tuning Functions |
|
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Built-in auto-tuning function lowers the barriers for users and optimizes machine performance with less tuning effort |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Provides step-by-step guidance wizard for easily tuning and setting up servos via panel keypad or software |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
![](http://www.deltaww.com/filecenter/Products/Images/06/060201/ASDA-A3_feature3_EN.jpg) |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
![](http://www.deltaww.com/filecenter/Products/Images/06/060201/ASDA-A3_feature4_EN.jpg) | |
|
|
|
Excellent Vibration Suppression |
|
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Advanced Notch Filter |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Provides 5 sets of notch filters with up to 5 kHz tunable bandwidth |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
The filters can search resonance in a shorter time and set the attenuation level automatically, avoiding damage to machines |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
![](http://www.deltaww.com/filecenter/Products/Images/06/060201/ASDA-A3_feature5_EN.jpg) |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Low Frequency Vibration Suppression Function |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Suppresses vibration for machines with high flexibility, enhancing overall performance |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Adopts a creative algorithm to eliminate the shaking of machines without slowing down its response and speed |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
![](http://www.deltaww.com/filecenter/Products/Images/06/060201/ASDA-A3_feature6_EN.jpg) | |
|
|
|
System Diagnosis Function |
|
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Measures the rigidity and damping coefficient of a machine and checks the consistency of the machine's batch installation |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Acquires the wear condition of a machine by comparing data from different time spans |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
![](http://www.deltaww.com/filecenter/Products/Images/06/060201/ASDA-A3_system.jpg) | |
|
|
|
Multi-axis DC-bus Sharing Design |
|
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Collects regenerative energy and stabilizes DC-bus voltage for energy savings |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Multiple servo drives with DC-bus sharing saves cost of resistors and installation space |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
![](http://www.deltaww.com/filecenter/Products/Images/06/060201/ASDA-A3_feature7_EN.jpg) | |
|
|
|
Slim and Compact Size Servo Drives and Motors |
|
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Drives and motors are 20% smaller and shorter than the ASDA-A2 Series, saving space |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
![](http://www.deltaww.com/filecenter/Products/Images/06/060201/ASDA-A3_feature8_EN.jpg) | |
|
|
|
Intuitive Software Interface |
|
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Tree-View index list and collapsible menu helps to access functions easily |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
Graphical interface provides set up functions and parameters, reducing setting time and failure |
![](http://www.deltaww.com/filecenter/ImagesNew/tab_dot.jpg) |
![](http://www.deltaww.com/filecenter/Products/Images/06/060201/ASDA-A3_feature9_EN.jpg) | |
|
